Product Description

The BioBlue Binocular Compound Microscope SMP 4/10/S40/S100x Objectives with Mechanical Stage delivers clear and vivid images at every level of magnification. Equipped with secure eyepieces and an adjustable rack stop, they ensure the safety of both samples and objectives. Designed specifically for educational use, prioritizing ergonomics and adhering to today's quality standards.

Features:

  • Enjoy clear and detailed observations with high-quality WF 10x/18mm Eyepieces, ensuring a comfortable viewing experience.

  • Integrated X-Y Mechanical Stage to position your specimens, allowing precise and controlled movement.

  • Height Adjustable Abbe Condenser with Iris Diaphragm and Filter Holder to achieve optimal illumination and contrast.

  • Comes equipped with rechargeable AA batteries and an integrated power supply.

  • Easily switch between different objectives using the reversed nosepiece, enabling seamless transitions during observation.

  • All optics are anti-fungus treated and anti-reflection coated for maximum light throughput.

  • Achieve precise focusing and control with the coaxial coarse and fine adjustments, ensuring accurate and smooth image manipulation. The rack stop prevents damage to samples and objectives.

  • Supplied with an intensity adjustable 1W NeoLED™ illumination system for increased light output. The innovative NeoLED™ design is a combination of a custom LED and a specially designed thin lens with a short focal length in order to obtain three main benefits:

    • More oblique light from the LED light source can be captured, which increases the light output significantly

    • Less energy is required to achieve this level of light intensity

    • The larger aperture of NeoLED™ allows the optical systems of the microscope to produce images at higher resolutions, very close to the theoretical diffraction limit of the optics.

  • Ergonomic Stand design to reduce strain and promote ergonomic posture during extended usage.

  • Ensure a hygienic and safe environment with the provided APL (Antimicrobial Protection Layer), minimizing the risk of contamination.

  • These microscopes meet the stringent quality and safety standards of CE certification.

  • A Kensington Security Slot located at the back of the microscope can be used to help secure the instrument from theft.

  • 10-Year Warranty

Technical Information:

Head
  • Binocular head has 30° inclined tubes, interpupillary is adjustable between 48 and 75mm, and equipped with a +/-5 diopter adjustment on the left eyepiece tube.
  • 360° rotatable and secured with a screw.
Eyepieces
  • Widefield WF10x/18mm
Nosepiece
  • Reversed quadruple (4) nosepiece on ball bearings
Objective (45mm parfocal)

Equipped with semi-plan objectives:

  • SMP 4x/0.10 WD 37.5mm
  • SMP 10x/0.25 WD 6.54mm
  • SMP S40x/0.65 spring WD 0.68mm
  • SMP S100x/1.25 spring, oil immersion WD 0.22mm
  • Total magnification 40x, 100x, 400x, 1000x
Stage
  • 130 x 130mm stage with mechanical
  • 70 x 28mm XY translation stage
Condenser
  • Abbe N.A. 1.25 with iris diaphragm
Focusing
  • Coaxial coarse and fine adjustments with 200 graduations. Precision 2 microns per graduation, 04mm per rotation.
  • Total travel range is approximately 23mm.
  • Supplied with an adjustable rack stop to prevent damage to sample and objectives.
  • The coarse adjustments are equipped with friction control.
Illumination
  • 1W NeoLED™, rechargeable batteries (cordless)
Package Contents
  • Smart Styrofoam packaging ensures a low environmental footprint while maintaining maximum safety during transport.
  • Supplied with power cord,  three rechargeable AA batteries, dust cover, a spare fuse, white filter, 5mL oil immersion, user manual.

Specifications

Specifications
Manufacturer Globe Scientific
Country of Manufacture China
Item Ships From New Jersey

Literature

pdf
(Size: 314.6 KB)
